StaticSmart
A tweed textural solid that has become the anchor of the StaticSmart® Plus line.
Description
Conductive Fiber: Continuous conductive StaticSmart® FibreLink monofilament
kV Rating: AATCC 134-06 (w/o conductive footwear) electrostatic propensity: less than 0.4 kV (400 Volts). Tested at 20% relative humidity at 20° Celsius and 70° Fahrenheit.
Electrical Resistance: ESD S7.1/NFPA 99 Resistive/resistance characterization of materials: Rtt six or more readings between points placed 3 feet apart. Tested with an applied voltage of 100V. Measured in Ohms, 2.5 x 10e4 minimum, 1.0 x 10e8 maximum. Rtg six or more readings from surface to groundable point. Tested with an applied voltage of 100V. Measured in Ohms, 2.5 x 10e4 minimum, 1.0 x 10e8 maximum
Electrical Resistance/Voltage Test: AANSI/ESD S20.20-2014, compliant when using approved conductive footwear. Results within required limits < 1 x 10e9 Ohms and < 100 Volts peak D.O.D. HDBK263A, Section 40.1.2: Meets recommended guidelines for sensitive ESD devices, Class 1. Exceeds FAA-STD-019e and Mo torola R56 standards and guidelines for static control flooring.
Roller Caster Electrical Test (CET) Assessment: After 100,000 chair caster cycles there was no depreciable change in conductivity or electrical performance.
Groundable Path: StaticSmart® ground strip or Rtg Connector Kit
Grounding Frequency: 1 per 1,000 sq. ft.
Backing System: Conductive Ecoworx® backing – 100% PVC-free recyclable, made from recycled material
Adhesives: Conductive releasable adhesive for carpet tile 1.0 x 10e6 Ohms Rtt
Installation Method(s):
Construction:
Fiber: Premium branded ECO solution Q solution dyed nylon
Backing: Conductive EcoWorx®
Face Weight: 24.0 oz./sq. yd.
Size: 24″ x 24″
Colors:
Houston
Crockett
Columbus Blue
Carson
Livingstone
Shackelton Grey
Galileo
Magellan
